SWITCHING CHARACTERISTICS
(Outputs loaded with 30 pF)
Notes: 10. After powering up the CS4223/4, PDN should be held low for 10 ms to allow the power supply to settle.
Parameter Symbol Min Typ Max Unit
Audio ADC’s and DAC’s Sample Rate Fs 4 - 50 kHz
XTI Frequency XTI = 256, 384, or 512 Fs 1.024 - 26 MHz
XTI Pulse Width High XTI = 512 Fs
XTI = 384 Fs
XTI = 256 Fs 13
21
31 -
-
- -
-
- ns
ns
ns
XTI Pulse Width Low XTI = 512 Fs
XTI = 384 Fs
XTI = 256 Fs 13
21
31 -
-
- -
-
- ns
ns
ns
XTI Jitter Tolerance - 500 - psRMS
RST Low Time (Note 10) 10 - - ms
SCLK falling edge to SDOUT output valid DSCK = 0 t
dpd
- - ns
LRCK edge to MSB valid t
lrpd
- - 45 ns
SDIN setup time before SCLK rising edge DSCK = 0 t
ds
25 - - ns
SDIN hold time after SCLK rising edge DSCK = 0 t
dh
25 - - ns
SCLK Period t
sckw
- - ns
SCLK High Time t
sckh
40 - - ns
SCLK Low Time t
sckl
40 - - ns
SCLK rising to LRCK edge DSCK = 0 t
lrckd
35 - - ns
LRCK edge to SCLK rising DSCK = 0 t
lrcks
40 - - ns
1
(384) Fs
---------------------- 20 +
1
(128) Fs
----------------------
sckh sckl
sckw t
t t
MSB MSB-1
*SCLK shown for DSCK = 0, SCLK inverted for DSCK = 1.
t dpd
SDOUT
LRCK
SCLK*
SDIN
dh
t
ds
t lrpd
t
lrcks
t lrckd
t
Figure 1. Serial Audio Port Data I/O Timing
