CS4223 CS4224
14 DS290F1
4. REGISTER QUICK REFERENCE - CS4224
Addr Function 7 6 5 4 3 2 1 0
0h Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved
default 0 0 0 0 0 0 0 0
1h ADC Control PDN HPDR HPDL ADMR ADML CAL CALP CLKE
default 0 0 0 0 0 0 0 0
2h DAC Control Reserved MUTC MUTR MUTL SOFT Reserved RMP1 RMP0
default 0 0 0 0 0 0 0 0
3h-4h Output Attenuator
Level
ATT7 ATT6 ATT5 ATT4 ATT3 ATT2 ATT1 ATT0
default 0 0 0 0 0 0 0 0
5h DSP Port Mode Reserved DEM1 DEM0 DSCK DOF1 DOF0 DIF1 DIF0
default 0 0 0 0 0 0 0 0
6h Converter Status
Report ACCR ACCL LVR2 LVR1 LVR0 LVL2 LVL1 LVL0
default 0 0 0 0 0 0 0 0
7h Master Clock
Control Reserved Reserved Reserved Reserved Reserved Reserved MCK1 MCK0
default 0 0 0 0 0 0 0 0
