CS4223 CS4224

20

DS290F1

6. PIN DESCRIPTIONS — CS4223

1

2

3

4

5

6

7

8

21

22

23

24

25

26

27

28

NC

RST

AOUTL-

AOUTL+

AOUTR+

AOUTR-

AGND

VA

SDOUT

DGND

VD

SCLK

LRCK

XTI

XTO

NC

9

10

11

12

17

18

19

20

AINL+

AINL-

DEM1

AINR+

DEM0

DIF0

DIF1

SDIN

13

14

15

16

AINR-

NC

NC

VL

CS4223

NC

1,14,15, 28 No Connect - These pins are not connected internally and should be tied to DGND to mini-

mize noise coupling.

XTI, XTO

2,3

Crystal Connections (Input/Output) - Input and output connections for the crystal used to
clock the CS4223. Alternatively, a clock may be input into XTI. This is the clock source for the
delta-sigma modulator and digital filters. The frequency of this clock must be either 256x, 384x,
or 512x Fs in Slave Mode and 256x in Master Mode.

LRCK

4

Left/Right Clock (Input) - Determines which channel is currently being input/output of the
serial audio data pins SDIN/SDOUT. The frequency of the Left/Right clock must be equal to the
input sample rate. Although the outputs for each ADC channel are transmitted at different
times, Left/Right pairs represent simultaneously sampled analog inputs. The required relation-
ship between the left/right clock, serial clock and serial data is defined by the DIF1-0 pins. The
options are detailed in Figures 8 - 11.

SCLK

5

Serial Data Clock (Input) - Clocks the individual bits of the serial data into the SDIN pin and
out of the SDOUT pin. The required relationship between the left/right clock, serial clock and
serial data is defined by the DIF1-0 pins. The options are detailed in Figures 8 - 11.

VD

6

Digital Power (Input) - Positive power supply for the digital section. Typically 5.0 VDC.

DGND

7

Digital Ground (Input) - Digital ground for the digital section.

SDOUT

8

Serial Data Output (Output) - Two's complement MSB-first serial data is output on this pin.
The required relationship between the left/right clock, serial clock and serial data is defined by
the DIF1-0 pins. The options are detailed in Figures 8 - 11.

Fs (kHz)

XTI (MHz)

256x

384x

512x

32

8.1920

12.2880

16.3840

44.1

11.2896

16.9344

22.5792

48

12.2880

18.4320

24.5760

Table 2. Common Clock Frequencies
