CS4223 CS4224
DS290F1 23
SDOUT 8 Serial Data Output (Output) - Two's complement MSB-first serial data is output on this pin.
The required relationship between the left/right clock, serial clock and serial data is defined by
the DSP Port Mode (05h) register. The options are detailed in Figures 8 - 11.
SDIN 9 Serial Data Input (Input) - Two's complement MSB-first serial data is input on this pin. The
required relationship between the left/right clock, serial clock and serial data is defined by the
DSP Port Mode (05h) register. The options are detailed in Figures 8 - 11.
SCL/CCLK 10 Serial Control Port Clock (Input) - Clocks the serial control bits into and out of the CS4224.
In I 2 C mode, SCL requires an external pull-up resistor according to the I 2 C specification.
SDA/CDIN 11
Serial Control Port Data (Input/Output)- SDA is a data I/O line in I
2
C mode and requires an
external pull-up resistor according to the I
2
C specification. CDIN in the input data line for the
serial control port in SPI mode.
AD0/CS 12
Address Bit/Control Chip Select (Input) - In I
2
C mode, AD0 is a chip address bit. In SPI
mode, CS is used to enable the control port interface on the CS4224. The CS4224 control port
interface is defined by the SPI/I2C pin.
VL 13 Logic Power (Input) - Positive power supply for the digital interface section. Typically 3.0 to
5.0 VDC.
AINR-, AINR+ 16,17 Differential Right Channel Analog Input (Input) - The full scale analog input level (differen-
tial) is specified in the Analog Characteristics specification table and may be AC coupled or DC
coupled into the device, see Figure 12 for optional line input buffer.
I2C/SPI 18 Control Port Format (Input) - When this pin is high, I
2
C mode is selected, when low, SPI is
selected.
AINL-, AINL+ 19,20 Differential Left Channel Analog Input (Input) - The full scale analog input level (differential)
is specified in the Analog Characteristics specification table and may be AC coupled or DC
coupled into the device, see Figure 12 for optional line input buffer.
VA 21 Analog Power (Input) - Positive power supply for the analog section. Typically 5.0 VDC.
AGND 22 Analog Ground (Input) - Analog ground reference.
AOUTR-,
AOUTR+ 23, 24 Differential Right Channel Analog Outputs (Output) - The full scale analog output level (dif-
ferential) is specified in the Analog Characteristics specification table.
AOUTL-, AOUTL+ 25, 26 Differential Left Channel Analog Outputs (Output) - The full scale analog output level (dif-
ferential) is specified in the Analog Characteristics specification table.
RST 27 Reset (Input) - When low, the device enters a low power mode and all internal registers are
reset, including the control port. When high, the control port becomes operational and normal
operation will occur.
