ANALOG CHARACTERISTICS (CONTINUED)
Notes: 7. The passband and stopband edges scale with frequency. For input word rates, Fs, other than 48 kHz,
the 0.01 dB passband edge is 0.4535x Fs and the stopband edge is 0.5465x Fs.
8. Digital filter characteristics.
9. Measurement bandwidth is 10 Hz to 3 Fs.
Parameter
Symbol
CS4223/4 - KS
CS4223/4 - BS/ - DS
Unit
Min
Typ
Max
Min
Typ
Max
Analog Output Characteristics - Minimum Attenuation, 10 k
Ω, 100 pF load; unless otherwise specified.
Signal-to-Noise, Idle-Channel Noise
(CS4224 only)
DAC muted, A-weighted
102
110
-
97
110
-
dB
Dynamic Range
DAC not muted, A-weighted
DAC not muted, unweighted
100
97
105
102
-
-
95
92
105
102
-
-
dB
dB
Total Harmonic Distortion
THD
-
0.0014
-
-
0.0014
-
%
Total Harmonic Distortion + Noise
THD+N
-
-97
-92
-
-97
-87
dB
Interchannel Isolation
(1 kHz)
-
90
-
-
90
-
dB
Interchannel Gain Mismatch
-
-
0.1
-
-
0.1
dB
Attenuation Step Size
All Outputs
0.35
0.5
0.65
0.35
0.5
0.65
dB
Programmable Output Attenuation Span
110
113.5
-
110
113.5
-
dB
Differential Offset Voltage
-
±10
-
-
±10
-
mV
Common Mode Output Voltage
-
2.4
-
-
2.4
-
V
Full Scale Output Voltage
1.8
1.9
2.0
1.8
1.9
2.0
Vrms
Gain Drift
-
100
-
-
100
-
ppm/°
C
Out-of-Band Energy
Fs/2 to 2 Fs
-
-60
-
-
-60
-
dBFs
Analog Output Load
Resistance
Capacitance
10
-
-
-
-
100
10
-
-
-
-
100
k
Ω
pF
Combined Digital and Analog Filter Characteristics
Frequency Response10 Hz to 20 kHz
-
±0.1
-
-
±0.1
-
dB
Deviation from Linear Phase
-
±0.5
-
-
±0.5
-
Degree
Passband: to 0.01 dB corner
0
-
21.8
0
-
21.8
kHz
Passband Ripple
(Note 8)
-
-
±0.01
-
-
±0.01
dB
Stopband
26.2
-
-
26.2
-
-
kHz
Stopband Attenuation
(Note 9)
70
-
-
70
-
-
dB
Group Delay (Fs = Input Sample Rate)
Left
Right
t
gd_L
t
gd_R
-
-
26/Fs
27/Fs
-
-
-
-
26/Fs
27/Fs
-
-
s
s
Power Supply
Power Supply Current
VA
VD
VL
Total Power Down
-
-
-
-
46
9
3
0.4
60
20
5
-
-
-
-
-
46
9
3
0.4
60
20
5
-
mA
mA
mA
mA
Power Supply Rejection Ratio
1 kHz
-
65
-
-
65
-
dB
