1. CHARACTERISTICS AND SPECIFICATIONS
(All Min/Max characteristics and specifications are guaranteed over the Specified Operating Conditions. Typical
performance characteristics and specifications are derived from measurements taken at nominal supply voltages
and T
A
= 25
°C.)
SPECIFIED OPERATING CONDITIONS
(AGND, DGND = 0 V, all voltages with respect to 0 V.)
ABSOLUTE MAXIMUM RATINGS
(AGND, DGND = 0 V, all voltages with respect to 0 V.)
WARNING: Operation at or beyond these limits may result in permanent damage to the device.
Normal operation is not guaranteed at these extremes.
Notes: 1. Any pin except supplies. Transient currents of up to 100 mA on the analog input pins will not cause SCR
latch-up.
2. The maximum over or under voltage is limited by the input current.
Parameter Symbol Min Nom Max Unit
Power Supplies Digital
Analog
Digital
| VA - VD |
VD
VA
VL
4.75
4.75
2.7
-
5.0
5.0
5.0
-
5.25
5.25
5.25
0.4
V
V
V
V
Ambient Operating Temperature Commercial (-KS)
Industrial (-BS/-DS)
T
AC
T
AI
-10
-40 -
- 70
85 °C
°C
Parameter Symbol Min Max Unit
Power Supplies Digital
Analog
VD
VA
-0.3
-0.3 6.0
6.0 V
V
Input Current (Note 1) - ±10 mA
Analog Input Voltage (Note 2) -0.7 VA + 0.7 V
Digital Input Voltage (Note 2) -0.7 VD + 0.7 V
Ambient Temperature Power Applied -55 +125 °C
Storage Temperature -65 +150 °C
