RADWAG Low profiled scales - Manual (Page 80)

- 80 -
21.8. Beam scales
Scale type:
WPT/4P2
600 C
WPT/4P2
1000 C
WPT/4P2
2000 C
WPT/4P2
3000 C
Max capacity 600kg 1000kg 2000kg 3000kg
Min capacity 4kg 10kg 20kg 20kg
Readability 0,2kg 0,5kg 1kg 1kg
Verification interval 0,2kg 0,5kg 1kg 1kg
Tare range -600kg -1000kg -2000kg -3000kg
Beam length 1,2m
Max. beam spacing 5m
Operation temperature -10°C to +40°C
Ingress protection rate IP 65 steel, IP 43 plastic
Power supply 230V AC, 50Hz / 11V AC, and 6×AA (NiMH)
Supplied from batteries Average operation when supplied from batteries 35h
Display LCD with backlight
Weight of scale with indicator 37kg
Dimensions of weight [mm] 1200 x 120 x 85mm
Scale type:
WPT/4P2
2000 C1
WPT/4P2
4000 C1
WPT/4P2
6000 C1
Max capacity 2000kg 4000kg 1000kg
Min capacity 20kg 40kg 40kg
Readability 1kg 2kg 2kg
Verification interval 1kg 2kg 2kg
Tare range -2000kg -4000kg -6000kg
Beam length 2m
Max. beam spacing 5m
Operation temperature -10°C to +40°C
Ingress protection rate IP 65 steel, IP 43 plastic
Power supply 230V AC, 50Hz / 11V AC, and 6×AA (NiMH)
Supplied from batteries Average operation when supplied from batteries 35h
Display LCD with backlight
Weight of scale with indicator 53kg 90kg
Dimensions of weight [mm] 2000x120x105mm 2000x120x155mm
