RADWAG Low profiled scales - Manual (Page 74)

- 74 -
Scale type:
WPT/4
1500 H8
WPT/4
1500 H8/9
WPT/4
1500 H9
WPT/4
3000 H8
Max capacity 1500kg 3000kg
Min capacity 10kg 20kg
Readability 0,5kg 1kg
Verification division 0,5kg 1kg
Range of tare -1500kg -3000kg
Operation temperature -10°C to +40°C
Ingress protection rating IP 68 platform, IP 66/67 indicator
Power supply
230V AC, 50Hz / 11V AC
and internal gell cell SLA 6V accumulator
Supplied from batteries Average operation when supplied from batteries 45h
Display LCD with backlight
Bridge dimension [m] 1,2 x 1,2 1,2 x 1,5 1,5 x 1,5 1,2 x 1,2
Weight of scale with
indicator
125kg 160kg 190kg 130kg
Platform height 88mm 111mm
Scale type:
WPT/4
3000 H8/9
WPT/4
3000 H9
WPT/4
3000 H10
WPT/4
6000 H10
Max capacity 3000kg 6000kg
Min capacity 20kg 40kg
Readability 1kg 2kg
Verification division 1kg 2kg
Range of tare -3000kg -6000kg
Operation temperature -10°C to +40°C
Ingress protection rating IP 68 platform, IP 66/67 indicator
Power supply
230V AC, 50Hz / 11V AC
and internal gell cell SLA 6V accumulator
Supplied from batteries Average operation when supplied from batteries 45h
Display LCD with backlight
Bridge dimension [m] 1,2 x 1,5 1,5 x 1,5 1,5 x 2
Weight of scale with
indicator
165kg 200kg 285kg 350kg
Platform height 111mm 166mm
