21.3. Stainless steel scales (pit version)
Scale type:
WPT/4
300 H6/Z
WPT/4
300 H7/Z
WPT/4
600 H6/Z
WPT/4
600 H7/Z
WPT/4
1500 H7/Z
Max capacity 300kg 600kg 1500kg
Min capacity 2kg 4kg 10kg
Readability 0,1kg 0,2kg 0,5kg
Verification division 0,1kg 0,2kg 0,5kg
Range of tare -300kg -600kg -1500kg
Operation temperature -10°C to +40°C
Ingress protection rating IP 68 platform, IP 66/67 indicator
Power supply
230V AC, 50Hz / 11V AC
and internal gell cell SLA 6V accumulator
Supplied from batteries Average operation when supplied from batteries 45h
Display LCD with backlight
Bridge dimension [m] 0,8 x 0,8 1 x 1 0,8 x 0,8 1 x 1
Weight of scale with
indicator
75kg 105kg 75kg 105kg 75kg
Platform height 88mm
Scale type:
WPT/4
1500 H8/Z
WPT/4
1500 H8/9/Z
WPT/4
1500 H9/Z
WPT/4
3000 H8/Z
Max capacity 1500kg 3000kg
Min capacity 10kg 20kg
Readability 0,5kg 1kg
Verification division 0,5kg 1kg
Range of tare -1500kg -3000kg
Operation temperature -10°C to +40°C
Ingress protection rating IP 68 platform, IP 66/67 indicator
Power supply
230V AC, 50Hz / 11V AC
and internal gell cell SLA 6V accumulator
Supplied from batteries Average operation when supplied from batteries 45h
Display LCD with backlight
Bridge dimension [m] 1,2 x 1,2 1,2 x 1,5 1,5 x 1,5 1,2 x 1,2
Weight of scale with
indicator
145kg 180kg 210kg 155kg
Platform height 88mm 111mm
