- 78 -
Scale type:
WPT/4F
150 C7
WPT/4F
300 C6
WPT/4F
300 C7
WPT/4F
300 C8
Max capacity 150kg 300kg
Min capacity 1kg 2kg
Readability 50g 100g
Verification division 50g 100g
Range of tare -150kg -300kg
Operation temperature -10°C to +40°C
Ingress protection rating IP 65 steel, IP 43 plastic
Power supply 230V AC, 50Hz / 11V AC, and 6×AA (NiMH)
Supplied from batteries Average operation when supplied from batteries 35h
Display LCD with backlight
Platform height * 57 / 66mm 59 / 68mm
Bridge dimension [m] 1 x 1 0,8 x 0,8 1 x 1 1,2 x 1,2
Inroad dimension [mm] 540 x 1000 560 x 800 560 x 1000 560 x 1200
Weight of scale with indicator 41,8kg 34,8kg 46,8kg 60,8kg
Inroad weight 16kg 14kg 17kg 20kg
* version with inroads / version without inroads
Scale type:
WPT/4F
600 C6
WPT/4F
600 C7
WPT/4F
600 C8
WPT/4F
600 C9
WPT/4F
600 C10
Max capacity 600kg
Min capacity 4kg
Readability 200g
Verification division 200g
Range of tare -600kg
Operation temperature -10°C to +40°C
Ingress protection rating IP 65 steel, IP 43 plastic
Power supply 230V AC, 50Hz / 11V AC, and 6×AA (NiMH)
Supplied from batteries Average operation when supplied from batteries 35h
Display LCD with backlight
Platform height * 74 / 86mm 79 / 91mm
Bridge dimension [m] 0,8x0,8 1x1 1,2x1,2 1,5x1,5 1,5x2
Inroad dimension [mm] 700x800 700x1000 750x1200 750x1500 750x1500
Weight of scale with
indicator
62,8kg 86,8kg 120,8kg 173,8kg 225,8kg
Inroad weight 23kg 28kg 36kg 48kg
* version with inroads / version without inroads
