- 77 -
Scale type:
WPT/4N
1500H2
WPT/4N
1500H3
WPT/4N
1500H4
Max capacity 1500kg
Min capacity 10kg
Readability 500g
Verification division 500g
Range of tare -1500kg
Operation temperature -10°C to +40°C
Ingress protection rating IP 68 platform, IP 66/67 indicator
Power supply
230V AC, 50Hz / 11V AC
and internal gell cell SLA 6V accumulator
Supplied from batteries Average operation when supplied from batteries 45h
Display LCD with backlight
Platform size 1,1 x 1,2m 1,2 x 1,5m 1,5 x 1,5m
Weight of scale with indicator 190kg 230kg 270kg
Dimensions of weight [mm] 2150x1420x77 2450x1520x77 2450x1820x77
21.5. Low profiled scales
Scale type:
WPT/4F
60 C5
WPT/4F
60 C6
WPT/4F
60 C7
WPT/4F
150 C5
WPT/4F
150 C6
Max capacity 60kg 150kg
Min capacity 400g 1kg
Readability 20g 50g
Verification division 20g 50g
Range of tare -60kg -150kg
Operation temperature -10°C to +40°C
Ingress protection rating IP 65 steel, IP 43 plastic
Power supply 230V AC, 50Hz / 11V AC, and 6×AA (NiMH)
Supplied from batteries Average operation when supplied from batteries 35h
Display LCD with backlight
Platform height * 57 / 66mm
Bridge dimension [m] 0,6x0,6 0,8x0,8 1x1 0,6x0,6 0,8x0,8
Inroad dimension [mm] 540x600 540x800 540x1000 540x600 540x800
Weight of scale with
indicator
22,8kg 30,8kg 41,8kg 22,8kg 30,8kg
Inroad weight 10kg 13kg 16kg 10kg 13kg
* version with inroads / version without inroads
