- 76 -
Scale type:
WPT/4
3000 H8/9/Z
WPT/4
3000 H9/Z
WPT/4
3000 H10/Z
WPT/4
6000 H10/Z
Max capacity 3000kg 6000kg
Min capacity 20kg 40kg
Readability 1kg 2kg
Verification division 1kg 2kg
Range of tare -3000kg -6000kg
Operation temperature -10°C to +40°C
Ingress protection rating IP 68 platform, IP 66/67 indicator
Power supply
230V AC, 50Hz / 11V AC
and internal gell cell SLA 6V accumulator
Supplied from batteries Average operation when supplied from batteries 45h
Display LCD with backlight
Bridge dimension [m] 1,2 x 1,5 1,5 x 1,5 1,5 x 2
Weight of scale with
indicator
195kg 230kg 320kg 385kg
Platform height 111mm 166mm
Notice:
Each scale has a bipartite openable weight pan.
21.4. Ramp scales
Scale type:
WPT/4N
400H1
WPT/4N
400H2
WPT/4N
800H2
WPT/4N
800H3
Max capacity 400kg 800kg
Min capacity 4kg 10kg
Readability 200g 500g
Verification division 200g 500g
Range of tare - 400kg - 800kg
Operation temperature -10°C to +40°C
Ingress protection rating IP 68 platform, IP 66/67 indicator
Power supply
230V AC, 50Hz / 11V AC
and internal gell cell SLA 6V accumulator
Supplied from batteries Average operation when supplied from batteries 45h
Display LCD with backlight
Platform size 840 x 860mm 1,1 x 1,2m 1,1 x 1,2m 1,2 x 1,5m
Weight of scale with indicator 105kg 180kg
Dimensions of weight [mm] 1710x1160x76 2050x1420x76 2350x1520x76
