6 Commissoning, operation
14
WIKA operating instructions digital indicator DI10
Indicator for wall mounting:
Fasten the wall mounting enclosure with adequate material (screws) at the
four mounting holes.
Screws are not part of scope of delivery. Please use screws
according to the material of the wall, where you want to install
the enclosure.
For electrical connection pass the cable through the high-strength cable
gland.
Close the enclosure with the attached screws and fasten the screw nut of the
cable gland. So ingress protection IP 65 is reached.
6.2 Electrical connection
device without setpoints
