Operating Instructions Temperature Indicating Controller CS4S
V1.1
•
10/2006
- 15 -
OUT2 proportional cycle setting
• Sets proportional cycle for OUT2.
• Not available if the option [DT2] is not applied or when OUT2 is
ON/OFF action.
• Setting range: 1 … 120 seconds
3 seconds
A1 setting
• Sets action point for A1 output.
• Not available if No alarm action is selected in A1 action selection
• Refer to (Table 5.3-1).
0 °C
A2 setting
• Sets action point for A2 output.
• Not available if option [2AS] or [2AL] is not applied or if No Alarm
action is selected in A2 action selection.
• Refer to (Table 5.3-1).
0 °C
. ,
XX.X
indicated
in turn
Heater burnout alarm setting
• Sets the heater current value for Heater burnout alarm.
• Self-holding is not available for the alarm output.
• Available only when the option [W1x] is added.
• Rating 5A : 0.0 … 5.0 A
Rating 10A : 0.0 … 10.0 A
Rating 20A : 0.0 … 20.0 A
Rating 50A : 0.0 … 50.0 A
0.0 A
Loop break alarm action time setting
• Sets the time to assess the Loop break alarm.
• Available only when the option [2AR] or [2AL] is applied.
• Setting range: 0 … 200 minutes
0 minutes
Loop break alarm action span setting
• Sets the temperature to assess the Loop break alarm.
• Available only when the option [2AR] or [2AL] is applied.
• Setting range: 0 … 150 °C (°F), 0.0 … 150.0 °C (°F) or
0 … 1500
0 °C
(Table
5.3-1)
Alarm action type
Setting range
High limit alarm
– (Input span) to input span °C (°F)
*1
Low limit alarm
– (Input span) to input span °C (°F)
*1
High/Low limits alarm
0 to input span °C (°F)
*1
High/Low limit range alarm
0 to input span °C (°F)
*1
Process high alarm
Input range low limit value to input range high limit value *2
Process low alarm
Input range low limit value to input range high limit value *2
High limit alarm with standby
– (Input span) to input span °C (°F)
*1
Low limit alarm with standby
– (Input span) to input span °C (°F)
*1
High/Low limits alarm with standby
0 to input span °C (°F)
*1
•
When input has a decimal point, the negative low limit value is –199.9, and the positive high limit
value is 999.9.
• All alarm actions except process alarms are ±deviation setting to the main setting.
*1: For DC input, the input span is the same as the scaling span.
*2: For DC input, input range low (high) limit value is the same as scaling low (high) limit value.
