3. Signs, symbols and abbreviations / 4. Function / 5. For your safety GB
3. Signs, symbols and abbreviations
4. Function
2-wire Two connection lines are intended for the voltage supply.
The supply current is the measurement signal.
3-wire Two connection lines are intended for the voltage supply.
One connection line is intended for the measurement signal.
The pressure prevailing within the application is transformed into a standardised electrical
signal through the deflection of the diaphragm, which acts on the sensor element with the
power supply fed to the transmitter. This electric signal changes in proportion to the pressure
and can be evaluated correspondingly.
5. For your safety / 6. Packaging / 7. Starting, operation
Potential danger of life or of
severe injuries.
GB
Notice, important informa-
tion, malfunction.
The product complies with
the applicable European
directives.
„ Please make sure that the pressure transmitter is only used within the over-
load threshold limit all the time!
„ Observe the ambient and working conditions outlined in section 7 „Technical
data”.
„ Ensure that the pressure transmitter is only operated in accordance with the provisions i.e.
as described in the following instructions.
„ Do not interfere with or change the pressure transmitter in any other way than described in
these operating instructions.
„ Remove the pressure transmitter from service and mark it to prevent it from being used
again accidentally, if it becomes damaged or unsafe for operation.
„ Take precautions with regard to remaining media in removed pressure transmitter. Remai-
ning media in the pressure port may be hazardous or toxic!
„ Have repairs performed by the manufacturer only.
Potential danger of burns
due to hot surfaces.
5. For your safety
„ Select the appropriate pressure transmitter with regard to scale range,
performance and specific measurement conditions prior to installing and
starting the instrument.
„ Observe the relevant national regulations and observe the applicable stan-
dards and directives for special applications.
If you do not observe the appropriate regulations, serious injuries and/
or damage can occur!
„ Please note that the pressure measuring instrument is suitable for clean, dry,
non-aggressive gases only.
„ Open pressure connections only after the system is without pressure!
6. Packaging
Has everything been supplied?
Check the scope of supply:
„ Completely assembled pressure transmitters
„ Inspect the pressure transmitter for possible damage during transportation. Should
there be any obvious damage, inform the transport company and WIKA without delay.
„ Keep the packaging, as it offers optimal protection during transportation (e.g. chan-
ging installation location, shipment for repair).
„ Ensure that the pressure connection thread and the connection contacts will not be
damaged.
7. Starting, operation
Required tools: wrench (flats 27), screw driver
!
Caution
Warning
!
Warning
!
Warning
