3 technical specifications - tp-121edid, Technical specifications - tp-121edid – Kramer Electronics TP-125EDID User Manual
Page 13
10
TP-121/3/5EDID, PT-110EDID - Your TP-121EDID
4.3
Technical Specifications - TP-121EDID
INPUTS:
Video: 1 VGA/UXGA on a 15-pin HD connector
Audio: 1 audio ANALOG 3.5mm mini jack
OUTPUT:
1 RJ-45 OUT connector
BANDWIDTH (-3dB):
Audio: 20Hz to 20kHz @0.5dB
RESOLUTION:
Up to WUXGA and 1080p
S/N RATIO:
Video: 58dB unweighted, 68.3dB @5MHz weighted
Audio: <-80dB
TOTAL GAIN:
Audio: Analog/analog: 0dB; Analog/SPDIF: –12dBFS
COUPLING:
AC
TND+N:
Audio: <0.01%
POWER CONSUMPTION:
12V DC, 540mA
OPERATING
TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
12.1cm x 7.18cm x 2.42cm (4.76" x 2.83" x 0.95") W, D, H
WEIGHT:
0.3kg (0.67lbs) approx.
ACCESSORIES:
Power supply
OPTIONS:
RK-3T 19” rack adapter
All measurements are based on the transmitter/receiver pair.
Specifications are subject to change without notice
