SL-14RC/N – Overview 3
3 Overview
The SL-14RC/N is a highly versatile master room controller that acts as an
all-in-one extended remote control panel for control of A/V equipment—especially
projectors and associated equipment—in any room (such as classrooms,
boardrooms, or auditoriums). It streamlines operations and simplifies control by
integrating audio, video, and computer-video sources into a centralized system.
Optional 3-button remote control panels are available which enable you to
remotely duplicate the functionality of front panel buttons.
The SL-14RC/N features:
•
12 configurable front panel buttons (configured using the K-Config
Configuration software)
Available on our Web site at: http://www.kramerelectronics.com/support/?soft=k-config
•
One configurable rotary up/down controller with direction indicator LEDs
(configured using the K-Config Configuration software)
•
One general purpose I/O port that can be configured as an analog input,
digital input, or digital output for interfacing with a variety of devices such as
sensors, switches, LEDs, and relays
•
Six bi-directional RS-232 ports that can control AV equipment such as
projectors, LCD and PDP displays, power amplifiers, switchers and scalers
•
Two relay contacts that can control other room items related to the AV
system, such as, raising and lowering drapes, screen or projector
•
IR control on two outputs (terminal blocks)
•
A USB port for uploading a configuration file located behind the front panel
of the SL-14RC and on the rear panel of the SL-14RCN
•
IR Learning that learns commands from any IR remote
•
Compatibility with Kramer Site-CTRL software for network remote control
and management over the Ethernet port
