VP-790 - Technical Specifications 39
39
9.1.3 SDI Input Resolutions
SMPTE 292M, SMPTE 259M-C and SMPTE 424M compliant, accepts 484i (480i),
576i, 720p, 1080i and 1080p single link formats at 270Mb, 1.485Gb or 2.97Gb
rates.
9.1.1 YUV, RGB and RGBS Input Resolutions
YUV, RGB and RGBS Input Resolutions
484i (480i) 576p (ED) 1080i @59.94 1080p @24 1080p @30
576i (SD) 720p 1080i @60 1080p @25
480p 1080i @50 1080p @23.98 1080p @29.97
Note that this input does not support computer SVGA signals. SVGA
signals should be passed via the PC IN 15-pin HD connector. The PC
input supports the separate H and V syncs.
9.1.2 CV and s-Video Input Resolutions
NTSC, PAL and SECAM.
9.2 Output Resolutions
This section defines the output resolutions.
9.2.1 HDMI Output Resolutions
Technical Specifications of the HDMI Output Signal
640x480@60 1280x1024@50 1680x1050@60 1080p25
640x480@75 1280x1024@60 1920x1200@60 1080p29.97
800x600@50 1280x1024@75 480i60 1080p30
800x600@60 1360x768@60 480p60 1080p50
800x600@75 1366x768@50 576i50 1080p59.94
1024x768@50 1366x768@60 576p50 1080p60
1024x768@60 1400x1050@50 720p50 2K50
1024x768@75 1400x1050@60 720p59.94 2K60
1280x768@50 1600x900@60 720p60
1280x768@60 1600x1200@50 1080p23.976
1280x800@60 1600x1200@60 1080p24
9.2.1 SDI Output Resolutions
SMPTE 292M, SMPTE 259M-C and SMPTE 424M compliant, accepts (484i) 480i,
576i, 720, 1080i and 1080p single link formats at 270Mb, 1.485Gb or 2.97Gb rates.
