VP-790 - Configuring the VP-790 via the OSD MENU Screens
Setting
Function
Frame Lock
Set the frame lock mode: Off, Source, Genlock or Auto
Off: the output is set to a fixed refresh rate defined by the frame rate setting (in
the Output menu,
Section
), which deviates from the input refresh rate,
even if both are nominally at the same rate. This causes occasional frame
dropping or repeat
Source: the output refresh rate follows the input refresh rate if locking is
possible
Genlock: the output refresh rate follows the vertical sync of an external signal
via the GENLOCK BNC connector, if locking is possible
Auto: Default setup
Locking is achieved by modulating the output clock and works if input and
output refresh rate are nominally at the same rate, e.g. when frame rate is set
to 60Hz and the video input is also 60Hz. If e.g. the video input rate is 50 Hz
and the Frame rate is set to 60Hz, the output will enter free run mode. When
Frame Rate is set to Auto, the matching frame rate is chosen.
When I/O lock is set to Auto and a Genlock source is present to the
GENLOCK BNC. If genlocking is not achievable, locking to the video source
frame rate is tried. If that is not possible the output is running in free-run mode.
When operating in the Multi-unit mode, the same frame lock should
be defined in all the units in the matrix.
Factory Reset Select Yes to reset your VP-790 to its preset default settings
Operation
Mode
Set the Operation Mode: PIP/Single or Multiunit
When selecting Multiunit, the Multiunit menu (see
Section
) replaces the
PIP Menu (see
Section
Processing
Mode
Set the processing mode: Gaming Mode, Medium Latency or Best Picture
Gaming Mode: provides lower quality processing but a speedy response
For applications that require a quick response such as simulations, medical
imaging or gaming applications
Medium Latency: provides medium quality picture processing
Best Picture: provides optimum picture processing resulting in a high quality
When operating in the Multi-unit mode, the same processing mode
should be defined in all the units in the matrix.
Language
Select the language: English (AE), English (BE) or Deutsch (German)
Network
Setup
Network settings configuration:
IP Address Type: Static or DHCP
IP Address: 192.168.001.039
Net Mask: 255.255.000.000
Controls
Setup
Controls configuration:
Menu Position: Center, top Left, Top Right, Bottom Left or Bottom right
Menu Timeout: 5 sec, 10 sec, 15 sec, 20 sec, 25 sec, 30 sec or Infinite
Input Lock: On or Off
Set to OFF so you can still use the SOURCE buttons on the front panel even
when the lock button is on
Save Lock: On or Off
Set to ON to save the lock status when the machine is powered down
