10 VP-790 - Connecting the VP-790
5 Connecting the VP-790
Always switch off the power to each device before connecting it to
your VP-790. After connecting your VP-790, connect its power and
then switch on the power to each device.
You do not have to connect all the inputs and outputs, connect only
those that are required.
To connect the VP-790, as illustrated in the example in Figure 3 , do the following:
1. Connect an SDI source (for example, an SDI digital camera) to the SDI IN
BNC connector.
2. Connect an s-Video source (for example, an s-Video player) to the Y/C IN
4-pin VIDEO INPUT connector.
3. Connect a component video source (for example, a component video player)
to the COMP/RGB IN P R , P B and Y, RCA connectors.
4. Connect an HDMI source (for example, a DVD player) to the HDMI IN
connector.
5. Connect a computer graphics source to the PC IN 15-pin HD VIDEO INPUT
connector.
6. Connect a DVI source (for example, a computer) to the DVI-D IN DVI
connector.
7. Connect a composite video source (for example, a composite video player)
to the CV 1 IN BNC connector.
8. Connect a composite video source (for example, a composite video player)
to the CV 2 IN RCA connector (not shown in Figure 3 ).
9. Connect an external sync source to the GENLOCK IN BNC connector (not
shown in Figure 3 ).
!
