Technical Specifications
24
8 Technical Specifications
The VS-88HD technical specifications are shown in Table 6 :
Table 6: VS-88HD Technical Specifications
1
INPUTS: 8 SMPTE-259M, 344M, 292M and 372M (dual link)
serial video, 75Ω on
BNC connectors
OUTPUTS: 8 equalized and reclocked SMPTE-259M, 344M, 292M and 372M (dual
link)
outputs 75Ω on BNC connectors
MAX. OUTPUT LEVEL: 800mVpp /
75Ω
DATA RATE: 1.485Gbps
EQUALIZATION: Automatic equalization for losses on 75
Ω coaxial cable
CONTROLS: Front-panel, RS-232, RS-485, ETHERNET, remote infrared
POWER SOURCE: Universal, 100-240V AC, 50/60Hz 24VA
DIMENSIONS: 19" x 7" x 1U W, D, H, rack mountable
WEIGHT: 2.6kg (5.7lbs) approx.
ACCESSORIES: Power cord, rack “ears” and IR remote control transmitter
OPTIONS: External remote IR receiver cable
9 Communication Parameters
The following table lists the communication parameters for Protocol 2000
and Protocol 3000.
Table 7: Communication Parameters
EDID
EDID data is passed between Input 1 and Output 1
RS-232
Protocol 2000 Protocol 3000 (Default)
Baud Rate: 9600 Baud Rate: 115,200
Data Bits: 8 Data Bits: 8
Stop Bits: 1 Stop Bits: 1
Parity: None Parity: None
Command Format: HEX Command Format: ASCII
Example (Output 1 to Input 1): 0x01, 0x81, 0x81, 0x81 Example (Output 1 to Input 1): #AV 1>1
Switching Protocol
P2000 -> P3000 P3000 -> P2000
Command: 0x38, 0x80, 0x83, 0x81 Command: #P2000
Front Panel: Press and hold Output 1 and Output
2 simultaneously Front Panel: Press and hold Output 1 and Output 3
simultaneously
Ethernet
Default Settings Reset Settings
IP Address: 192.168.1.39 Power cycle the unit while holding in the Factory Reset button,
located on the rear panel of the unit.
TCP Port #: 5000
UDP Port #: 50000
1 Specifications are subject to change without notice
