Connecting the VS-88HD
9
9
6 Connecting the VS-88HD
This section describes how to connect the VS-88HD in single link mode
(see section
6.1 ) and in dual link mode (see section 6.2 ).
6.1 Connecting the VS-88HD in the Single Link Mode
The VS-88HD can switch one of the eight SDI/HD-SDI inputs to any or all
of the eight SDI/HD-SDI outputs, as the example in
Figure 2 shows.
To connect the VS-88HD 8x8 HD-SDI Matrix Switcher, do the following
1
1. Connect up to eight SDI sources to the SDI INPUT BNC connectors (for
example, an HD/SD camera to INPUT 1 and an SDI player to INPUT 8).
:
2. Connect the SDI OUTPUT BNC connectors to up to eight SDI acceptors
(for example, OUTPUT 1 to a non-linear editor, and OUTPUT 8 to an HD
SDI display).
3. Set the DIP-switches (see section 6.4.2 ).
4. Optionally
2
• A genlock source to the GENLOCK BNC connector
, connect:
• The LOOP BNC connector to the GENLOCK connector of the
next unit in the line, and release the TERM button for looping
3
5. Connect a PC and/or controller (if required), to the:
• RS-232 port (see section
6.4 ), and/or
• RS-485 port (see section
6.5 ), and/or
• ETHERNET connector (see section
6.7 )
6. Connect the power cord
4
1 Switch OFF the power on each device before connecting it to your VS-88HD. After connecting your VS-88HD, switch on
its power and then switch on the power on each device
.
2 Not illustrated in Figure 2
3 Pushed in terminates the input. Release when the input extends to another unit
4 We recommend that you use only the power cord that is supplied with this machine
