KRAMER: SIMPLE CREATIVE TECHNOLOGY
Technical Specifications
30
7 Technical Specifications
Table 9 includes the technical specifications:
Table 9: Technical Specifications
1
of the VS-81ETH 8x1 Universal CAT 5 Switcher
INPUTS:
8 RJ45 CAT-5 ports
OUTPUTS:
1 RJ45 CAT-5 port
BANDWIDTH (-3dB):
3 Gbits/sec
CONTROLS:
9 illuminated front-panel touch switches, RS-232, RS-485, contact closure,
Ethernet, IR
POWER SOURCE:
8 Watts (maximum) 100-264 VAC, 50/60Hz
DIMENSIONS:
19-inch (W), 7-inch (D), 1U (H)
WEIGHT:
2.5kg (5.5lbs) approx.
ACCESSORIES:
Power cord, Null modem adapter, Windows®-based control software,
Windows®-based Configuration Manager XPort software and Com Port
Redirector
8 Table of Hex Codes for Serial Communication
Table 10 lists the Hex values for a single machine (MACHINE # 1):
Table 10: VS-81ETH Hex Codes for Switching via RS-232/RS-485
IN/OUT 1
IN/OUT 2
IN/OUT 3
IN/OUT 4
IN/OUT 5
IN/OUT 6
IN/OUT 7
IN/OUT 8
7
8
1 Specifications are subject to change without notice
