Connecting and Controlling the VS-81ETH
18
Table 7 describes the Web Manager window buttons.
Table 7: Web Manager Window Buttons
Button Function
Unit Configuration Press to enter the Server Configuration and the Port Configuration
settings (section 5.6.4.1)
Server Properties Press to enter the Server Properties and change the server properties
by editing any of the fields (section 5.6.4.2)
Port Properties Press to enter the Port Properties and modify them
Factory Settings1 Press to set to factory default settings
Update Settings Press to update settings
Channel 1 Disabled
When in the Web Manager window:
1. Use the menu buttons to navigate to sub pages where you can configure
server settings. See explanations of the configuration parameters in the
following sections.
2. When you are finished, click the Update Settings button to save your
settings.
5.6.4.1 Unit Configuration Button
Click the Unit Configuration button to display the following dialog box
(Figure 14). This page contains the Server Configuration and the Port
Configuration settings. These are static settings read from the device.
Figure 14: Server Configuration in the Unit Configuration Window
Figure 14 and Figure 15 show the information available in the Unit
Configuration window.
