Contents
ii
Figure 9: Internet Protocol (TCP/IP) Properties Window 13
Figure 10: XPort™ Installer Main Dialog Box 15
Figure 11: Device Found on the Network 15
Figure 12: IP Address Assignment Dialog Box 16
Figure 13: Ethernet Port Web-Manager 17
Figure 14: Server Configuration in the Unit Configuration Window 18
Figure 15: Port Configuration in the Unit Configuration Window 19
Figure 16: Server Properties in the Unit Configuration Window 19
Figure 17: Serial Port Settings Window 20
Figure 18: Dedicated Connection Window 20
Figure 19: Flush Mode Input Buffer Window 20
Figure 20: Com Port Redirector Welcome Screen 21
Figure 21: Setup Complete Dialog Box 22
Figure 22: Com Port Redirector Configuration Window 22
Figure 23: Port Setup Window 23
Figure 24: IP Service Setup Dialog Box 24
Figure 25: Port Settings Window 25
Figure 26: Silent Mode Checked in the RDCfg Window 26
Figure 27: Connecting a Remote Mechanical Switcher Unit to the VS-81ETH 27
Figure 28: Control Configuration via RS-232 and RS-485 28
Tables
Table 1: Front Panel VS-81ETH 8x1 Universal CAT 5 Switcher Features 4
Table 2: Rear Panel VS-81ETH 8x1 Universal CAT 5 Switcher Features 4
Table 3: CAT5 PINOUT 8
Table 4: Machine # Dipswitch Settings 11
Table 5: Crossover Cable RJ-45 PINOUT 12
Table 6: Straight-through Cable RJ-45 PINOUT 14
Table 7: Web Manager Window Buttons 18
Table 8: Port Settings Description 25
Table 9: Technical Specifications of the VS-81ETH 8x1 Universal CAT 5 Switcher 30
Table 10: VS-81ETH Hex Codes for Switching via RS-232/RS-485 30
Table 11: Protocol Definitions 31
Table 12: Instruction Codes for Protocol 2000 32
