VS-808TP - Overview
3
3 Overview
Thank you for purchasing the Kramer VS-808TP 8x8 Twisted Pair Matrix Switcher.
This unique matrix switcher which utilizes economical TP (Twisted Pair) cabling
often pre-installed in buildings these days, routes and distributes signals both from
a local and/or remote source, and at extended ranges. It is designed especially for
installations where a high level of control possibilities is required from extended
distances. Typical uses include presentation and multimedia applications, as well
as long-range graphics distribution and control for schools, hospitals, security, and
stores.
The VS-808TP features:
•
Eight inputs and eight outputs for remote connection to compatible TP
transmitters and receivers
•
A switchable local input (built-in transmitter) and output (built-in receiver)
allowing direct connection of the signals (up to WUXGA, audio and RS-232)
for the units located near to the switcher (TP-133/TP-134 only)
•
Follow or breakaway switching for audio signals
•
Baud rate of up to 115200 for full-duplex RS-232
•
Two-line LCD display for separate route indication of video, audio or RS-232
•
Control via front panel buttons, RS-232, RS-485 and Ethernet
•
15 user-programmable presets for quick-change configurations
•
Kramer 2000 communication protocol (limited)
•
100-230V AC worldwide power supply
•
Standard 1U 19” rack mount size
