SPECIFICATIONS
VP-31 VP-32xl VP-61RS
Configuration 3:1 3:1 x 2 6:1
Input Type 3 VGA/XGA 3 VGA/XGA,
3 stereo audio, line level
6 VGA/XGA
Input
Connections
HD 15F connectors Video: HD 15F connectors
Audio: RCA connectors
HD15F connectors
Input Level 0.7Vpp/75ohm,
H&V syncs, TTL level
0.7Vpp/75ohm,
H&V syncs, TTL level Audio:
5Vpp/50K
0.7Vpp/75ohm,
H&V syncs, TTL level
Output Type 1 VGA/XGA 2x1 VGA/XGA
2x1 stereo audio, line level
1 VGA/XGA
Output
Connector
HD 15F connector Video: HD 15F connectors
Audio: RCA connectors
HD15F connector
Output Level 0.7Vpp/75ohm,
H&V syncs, TTL level
0.7Vpp/75ohm,
H&V syncs, TTL level Audio:
5Vpp/50K
0.7Vpp/75ohm,
H&V syncs, TTL level
Controls 3 electronic illuminated touch
switches with electronic
interlock.
3 electronic illuminated touch
switches with electronic
interlock. Terminal block
connector for remote control
6 electronic illuminated touch
switches with electronic
interlock. RS-232 via an
additional DB-9 connector on
the back panel.
Output
Coupling
Direct transmission by relay Direct transmission by relay Direct transmission by relay
Max. Video
Level
Up to 5V on 75ohm/0.25W
load (relay)
Up to 5V on 75ohm/0.25W
load (relay)
Up to 5V on 75ohm/0.25W
load (relay)
Video
Bandwidth
Exceeding 450MHz Exceeding 300MHz 180MHz
Differential
Gain
0.05% 0.1% 0.04%
Differential
Phase
0.02Deg. 0.06Deg. 0.02Deg.
K-Factor <0.05% <0.05% <0.05%
Non Linearity <0.05% 0.1% <0.1%
Video S/N
Ratio
73dB 75dB 72.7dB
Audio
Bandwidth
NA 100KHz NA
Audio S/N
Ratio
NA 95dB NA
Audio THD NA <0.018% NA
Max. Audio
Level
NA >5Vpp NA
Switch Time <5mS <5mS <5mS
Dimensions
(W, D, H)
24.5 x 18 x 4.5 (cm)
9.6" x 7" x 1.8"
22 x 18 x 4.5 (cm)
8.7" x 7" x 1.8"
48.3 x 17. 8 x 9 (cm)
19" x 7" x 1U
Weight 1.4kg. (3.1lbs.) Approx. 1.1kg. (2.4lbs.) Approx. 2.7kg. (6lbs.) Approx.
Power
Consumption
5.1VA 1.8VA 6.2VA
Power Source 230VAC, 50/60 Hz (115VAC,
U.S.A.)
12VDC, 150mA 230VAC, 50/60 Hz (115VAC,
U.S.A.)
