Kramer Electronics VP-31 - Manual (Page 17)

Input Description Labels
Used by the operator to name a selected input. The input name is saved when the Save button is clicked.
Setup Description Labels
Used by the operator to name each setup. The setup names correspond to the Setup window numbers and
are stored when the Save button is clicked.
10.1.3 Using the PC Control Software
Included with your switcher are diskettes with software drivers for the following products as shown on the
Switcher screen:
After installing the program perform the following steps (The VP-61RS is an example in this case):
1) Connect your switcher or matrix to an identified serial port of the PC.
2) Turn on the switcher/matrix.
3) Open the folder where the program was installed (the default folder is named K-Switch) and double click
on the K-switch icon. You may create a shortcut to the program and locate it in a convenient location.
4) When the program is launched for the first time, the Port screen appears together with the Switcher
screen. Select the active serial port ( COM1-COM4) to which the switcher/matrix is connected and then
click Ok. The Port screen disappears and the Switcher screen remains.
5) Select the desired switcher model and then click the Select button to confirm your selection.
NOTE
If the program was launched before, the Main Menu
appears immediately with the previously saved
configuration!
6) The Main Menu (with the switcher model number on top) appears.
