8
• LIFT PLATFORM MOTION ADJUSTMENTS
Liftkleen models are furnished with an
Agitating Lift Platform and are provided
with adjustments for the lift platform speed
and agitation frequency. The speed of the lift
platform movement can be varied by
adjusting the speed control mufflers as
follows:
CAUTION
When turning air on or off or when operating
the lift platform, stay clear of the lid, lift
platform and operating mechanism as the lid
could unexpectedly open or the platform
operate.
(1) Activate the operation by setting the
selector switch to the "ON" position and
depressing the "Start" button.
(2) Adjust speed control mufflers until
desired platform motion is obtained.
The frequency of agitation is dependent on
load, e.g. heavy loads will decrease
frequency while light loads will increase
frequency.
• SUPERFLO PUMP DISCHARGE
DIRECTION ADJUSTMENT
On Liftkleen models furnished with the
optional Superflo Pump unit, the discharge
nozzle from the pump (shown on Figure 17)
can be adjusted to provide various liquid
motions. The nozzle is set at the factory to
provide maximum turbulence - a combination
of horizontal and vertical fluid movement. To
obtain primarily horizontal movement of the
fluid, loosen locking set screw and rotate the
nozzle so that its discharge is parallel to the
back of the tank and the bottom.
CAUTION
Never direct the discharge upward as
splashing could occur which would create a
potential hazard.
!
!
MAINTENANCE
WARNING
Follow all Lock Out procedures before
performing any service or maintenance.
LOCK OUT PROCEDURES
• When performing any maintenance tasks on the
Liftkleen be sure that the master on/off air line
valve is in the “OFF” position (see Figure 14).
• Disconnect the main air supply to the rackand/or
lid cylinders to remove residual air
pressure.
• Also, turn electric power to machine “OFF” at
main disconnect.
LUBRICATION
• Lubricate the lift channels or roller track (Figure
18) with machinery grade grease. It is
recommended that this lubrication be done at
least every month.
• Lubricate the lid hinges (Figure 18) by oiling
with light machinery oil (SAE 30W or equivalent).
This should be done every month.This includes
the lid hinges and the lid opening
mechanism.
Entire lid mechanism should be inspected for wear,
especially hinges and bolt attaching lift to cover.
PNEUMATIC SYSTEM
• The filter/regulator/lubricator unit on the side of
unit (shown on Figure 14) must be checked at
least weekly. The moisture in the filter bowl is
drained by opening the drain valve at the
bottom
of the unit. This is especially important during hot
weather and may require more frequent attention.
The lubricator must be filled as required with
SAE
1 0W oil or its equivalent and set approximately
at 3 drops per minute. DO NOT use synthetic oil in
the machine's FLR. Synthetic lubricants may cause
o-rings, in the machine's air logic system, to swell
and fail.
The pressure regulator is adjustable
between 60 - 110 PSI. Remember, the unit's lifting
capacity changes as the air pressure goes up and
down. Recomended pressure is 90 - 100 PSI.
Recommended
Recommended pressure is 90
90 - 100 PSI. !
