PART NO. DESCRIPTION
PART NO. DESCRIPTION
1 Motor
2 661-16442 Vapor Screen
3 532-12960 Vapor Diffuser
4 744-15258 Gasket
5 724-05658 Pipe Plug, 3/4 NPT
6 753-02679 Set Screw
7 432-16608 Nozzle
8 602-18496 Reducing Tee
9 720-04148 Nipple
10 752-02971-12 Screw
11 528-16563 Bearing Retainer
12 744-15671 Slinger
13 646-23152-81 Pump Mounting Lid
14 752-02913-12 Screw
15 753-00817 Set Screw
16 573-13728-08 Coupling
17 438-23841-S Column Assembly
18 561-25950-63 Shaft
19 765-04108-81 Spring
20 752-07862-12 Screw
21 754-03510-18 Flat Washer
22 525-16258-74 Impeller
23 517-23427 Upper Volute
24 744-15498 Volute Gasket
25 518-16755 Lower Volute
26 752-03935-12 Screw
27 543-16580-74 Castle Nut
28 756-00893-81 Cotter Pin
29 754-18294-88 Drive Washer
30 760-06508 Bushing
31 760-18308 Sleeve
746-90804 Pneumatic Lid Lift 2 1 ⁄
2
˝Øx23˝ STR
746-90807 LKR-36 4˝Øx29˝ STR
746-90805 LKR 36 5˝Øx29˝ STK
Increased Lift
746-90807 LKR 48 4˝Øx29˝ STK
746-90805 LKR 48 5˝Øx29˝ STK
Increased Lift
746-90805 LKR 60 5˝Øx29˝ STK
746-90805 LKR 60 (2)5˝Øx29˝ STK
Increased Lift
746-90806 LKD 60 5˝Øx39˝ STK
746-90806 LKD 60 (2)5˝Øx39˝ STK
Increased Lift
746-90806 LKD 72 5˝Øx39˝ STK
746-90806 LKD 72 (2)5˝Øx39˝ STK
Increased Lift
459-23982 Roller Assembly (includes
bearings) for LKR & LKD
PUMP ASSEMBLY REPLACEMENT PARTS
See Figure 16 for diagram
MISCELLANEOUS MECHANICAL PARTS
CYC. NO. APPLICATION CYL. SIZE
AIR CYLINDERS
