15
PNEUMATIC SYSTEM COMPONENTS
PART NO. DESCRIPTION PART NO. DESCRIPTION
LKR/LKD COLD AND HEATED UNITS
738-90652 Emergency Stop button
738-90664 3-Way Valve, green
738-90637 3-Way Valve, black
738-90638 3-Way Switch
738-90642 4-Way Pilot Valve
738-90641 3-Way Valve
738-90843 Limit Valve
738-90844 Limit Valve Roller Arm Only
738-90672 Manifold Valve
738-90643 Pressure Pilot Valve, 3-Way
738-90639 Pressure Pilot Valve, 4-Way
738-90640 Impulse Relay Valve
738-90649 Valve
746-06130 Air Filter Regulator Lubricator Kit
738-90688* Speed Control Elbow Valve
746-06496 Speed Control Muffler, 1/2˝ NPT
451-24446‡ Safety Link Assembly
738-90777 4-Way Valve / 2 positions
738-90848 Pilot Operated Check
746-06209 Speed Control Mufler 1/4 NPT
746-06904 Muffler 1/8 NPT
CYCLE TIMER COMPONENTS (LKT-4)
780-90650 Timer
738-90638 3-Way Switch
738-90642 4-Way Pilot Valve
738-90649 Valve
ANTI-TIE DOWN COMPONENTS (LKT-AT)
746-90655 Anti-Tie Down, two hand control
738-90640 Impulse Relay Valve
738-90649 Valve
738-90847 3-Way Pilot Valve
* Not on manual lid models
‡Cold units only
REPLACEMENT PARTS
ELECTRICAL & HEATING SYSTEM
IMMERSION TYPE HEATERS, 4.5 KW
780-06112 240 V, 1-Ph, 60/50 Hz (B)
780-06077 240 V, 3-Ph, 60/50 Hz (J)
780-06080 480 V, 3-Ph, 60/50 Hz (Y)
780-06164 575 V, 3-Ph, 60/50 Hz (Z)
781-06081-81 Protective Well
780-06079 Thermostat
780-06364 Control Transformer
MOTOR PROTECTION COIL (HEATERS)
780-06250 240 V, 1-Ph, 60 Hz
780-06246 240 V, 3-Ph, 60 Hz
780-06247 480 V, 3-Ph, 60 Hz
780-06248 575 V, 3-Ph, 60/50 Hz
MAGNETIC CONTACTOR
780-06078 240/480/575 V
MANUAL STARTER
780-06245 1- and 3-Phase
746-06237 Thermometer 3˝ Dial
780-06148 7-Day Heating Timer (LKT-1)
MOTORS, LKR/D 1 1 ⁄
2
HP
370-06061 230V, 1 Ph, 60 Hz (B)
370-03918 230/460 V, 3 Ph, 60/50 Hz (J) or
(Y)
370-06149 575V, 3 Ph, 60 Hz (Z)
PART NO. DESCRIPTION PART NO. DESCRIPTION
