© MuxLab Inc. Active Component Video Balun Kit Installation Guide
Page 6
2.
Technical Specifications
Environment Component Video with Analog Stereo and/or Digital Audio,
IR-Emitter Pass-Through
Devices DVD Players, Satellite Receivers, PCs, laptops, CRT monitors, LCD monitors,
plasma screens, DLP projectors
Transmission Transparent to the user
Bandwidth Up to 220 MHz (1080p)
Input Impedance Video & Digital Audio RCA: 75 ohms; Stereo Audio: 2.2 Kohms
Output Impedance Cat 5e: 100 ohms
Connectors: Transmitter Component Input: 3 x female RCAs
Stereo Audio Input: 2 x female RCAs
Digital Audio Input: female RCA
IR-Emitter Pass-Through: 2 position terminal block
Transmitter Output (Cat 5e): RJ45 shielded
Connectors: Receiver Receiver Input (Cat 5e): RJ45 shielded
Component Output: 3 x female RCAs
Stereo Audio Output: 2 x female RCAs
Digital Audio Output: female RCA
IR-Emitter Pass-Through: 2 position terminal block
Max Distance:
Component Video
(Y/Pb/Pr) via Cat 5e UTP
Cable
(or better) 480i/p: 1,000 ft (305 m)
720p/1080i: 500 ft (152 m)
1080p:
500 ft (152 m)
Max Distance:
Audio (Stereo/Digital)
via Cat 5e UTP Cable
(or better) Analog Stereo Audio: 1,000 ft (305 m)
Digital Audio: 1,000 ft (305 m)
RJ45 Pin Configuration
Reverse Polarity
Sensitive
Use EIA/TIA 568A or 568B
straight-through wiring Green (Y): Pin 1 (R) Pin 2 (T)
Blue (Pb): Pin 4 (R) Pin 5 (T)
Red (Pr): Pin 7 (R) Pin 8 (T)
IR-Emitter Pass-Through: Pin 3 (R) Pin 6 (T)
Brightness Adjustment Brightness control via rotary switch on the receiver
(Factory default setting: “None”)
Sharpness Adjustment Sharpness control via potentiometer on the receiver
(Factory default setting: Completely rotated counterclockwise)
LED Indicators Tx Balun: Power: One (1) green LED
Rx Balun: Power: One (1) green LED
Cable Cat 5e unshielded twisted pair (or better)
Power Supplies 110-240V/12VDC/0.5A, 12VDC power jacks
Removable AC blades included for North America, Continental Europe &
UK
Temperature Operating: 0º C to 40º C
Storage: -10º C to 70º C
Humidity: Up to 95% non-condensing
Enclosure Black. ABS fire retardant plastic
Dimensions 6” x 4.25” x 1.50” (15.3 cm x 10.8 cm x 3.8 cm)
Weight 2.8 lbs (1.3 kg)
Regulatory FCC/CE, RoHS
Warranty Two (2) years
Order Information 500090: Active Component Video Balun Kit
