© MuxLab Inc. Active Component Video Balun Kit Installation Guide
Page 14
4.
Troubleshooting
The following table describes some of the problem symptoms, the
probable causes and possible solutions. If the information below
does not solve the problem, the technical support contact
information can be found at the end of this section.
Problem LED (Tx)
Power
LED (Rx)
Power
Probable Cause Possible
Solution
No Image OFF OFF No power Check power
connections
No Image OFF ON No power at
Transmitter Check power
connections
No Image ON OFF No power at
receiver Check power
connections
No Image ON ON Source not present
or cable problem Check component
cable
No Image ON ON Cat 5 cable Check continuity
Check correct
wiring
Smearing ON ON Cable length
exceeded Reduce cable
length
Adjust Brightness
and Sharpness
Ghosting ON ON Impedance
mismatch Check cabling
Try different
source or display
Wrong
Colors
ON ON Swapped pairs Check wiring
Loss of
Detail
ON ON Cable length
exceeded Reduce cable
length
Adjust Sharpness
Shaky
Image ON ON Too much gain Reduce cable
length
Adjust Brightness
and Sharpness
