Muxlab Active Component Video Balun Kit User Manual
Page 13
© MuxLab Inc.
Active Component Video Balun Kit Installation Guide
Page 13
14. The brightness rotary switch adjusts the luminance
level to compensate for low frequency signal loss
due to the Cat 5e/6 cable.
15. The sharpness potentiometer adjusts the equalization
to compensate for high frequency signal loss due to
the Cat 5e/6 cable.
16. Figure 4 shows the final configuration.
Figure 4: Typical Configuration
