Cover
Standard cover
• The 318 is supplied with a PFA Teflon-lined cover to fit a clamped outside single seal
Optional covers
• a bolt-on metallic seal chamber for conventional back-to-back double seals
• PFA Teflon-lined standard-bore stuffing-box cover is available for conventional single-clamped inside
or outside seals.
• For cartridge seals, an ETFE Tefzel-lined BigBore seal chamber is available.
This table describes the main parts of the power end.
Table 4: Power end
Part Description
Frame adapter The ductile iron frame adapter has
• a machined rabbet fitted to the seal chamber/ stuffing box cover
• a precision dowel pin fitted to the bearing frame.
The 3198 frame adapter has the same features but different dimensions to
accommodate the pump’s Teflon lining.
Power end • Flood-oil lubrication is standard.
• No machining is required to convert from oil to grease or oil-mist lubrication.
Regreasable bearings and oil-mist lubrication are optional.
• The oil level is checked through a sight glass.
• The power end is sealed with labyrinth seals.
• The power end is made in the following sizes:
• STi
• MTi
Shaft The shaft is available with or without a sleeve.
When supplied with a Teflon sleeve, the 3198 shaft is knurled under the sleeve to
provide a positive drive for the sleeve.
Bearings The inboard bearing
• carries only radial loads.
• is free to float axially in the frame.
• is a single-row deep-groove ball bearing
The outboard bearing
• is shouldered and locked to the shaft and housing to enable it to carry radial
and thrust loads.
• is a double-row angular-contact bearing.
General description i-ALERT ™ Condition Monitor
Description
The i-ALERT Condition Monitor is a compact, battery-operated monitoring device that continuously
measures the vibration and temperature of the pump power end. The condition monitor uses blinking red
LEDs to alert the pump operator when the pump exceeds pre-set vibration and temperature limits. This
allows the pump operator to make changes to the process or the pump before a catastrophic failure
occurs. The condition monitor is also equipped with a single green LED to indicate when it is operational
and has sufficient battery life.
Alarm mode
The condition monitor enters alarm mode when either vibration or temperature limits are exceeded over
two consecutive readings within a ten minute period. Alarm mode is indicated with two red flashing LEDs
within two second intervals.
Product Description
