Item Quantity Part name
Pump Material (3196,
HT 3196, CV 3196,
3796)
Pump Material (NM
3196)
Pump Material
(3198)
All Titanium
Vinylester
D.I./Teflon
497N 1
O-Ring Internal (outboard)
Viton
503
1
Adapter Ring
1013
529
1
Lockwasher—Frame Foot-to-Bearing
Frame
Steel
555
1
Tube, Finned Cooling Assembly
304AA / Copper
555A 1
Tube, Ftg Male (Frame Cooling)
Brass
555B 2
Connector, Thermocouple (Frame
Cooling)
Brass
555C 2
Elbow, Female (Frame Cooling)
Brass
555D 1
Conn TC Sealed PWR
Cast iron
761B 1
i-ALERT
™
Condition Monitor
Stainless steel/epoxy
Table 25: Key to table symbols
–
Not applicable
*
Only applicable for HT 3196
**
3 for STi, MTi
****
4 for 6 in. STi
8 for 8 in. STi and MTi
16 for 13 in. MTi
12 for 10 in. MTi
Table 26: Material-code reference
Material
Goulds material
code
ASTM
Din
ISO
JIS
Cast Iron
1001
A48 CLASS 20
Ductile Iron
1012
A395 Gr60-40-18
Ductile Iron
1013
A536 Gr60-42-10
CD4MCu
1041
A744 CD4MCU
Monel
1119
A494 GrM-35-1
316SS
1203
A744 CF-8M
1.4408
G5121 (SC514)
Alloy 20
1204
A744CN-7M
1.4500
317SS
1209
A744CG-8M
1.4448
Hastelloy C
1215
A494 CW-6M
CD4MCu
1216
A744CD4MCU
9.4460
Hastelloy B
1217
A494 N-7M
Titanium
1220
B367 GrC-3
Nickel
1601
A494 GrCZ100
Monel
2150
B164 UNS N04400
Nickel
2155
B160 UNS N02200
Titanium
2156
B348 Gr2
Carbon Steel
2201
A576 Gr. 1018 and
1020
Carbon Steel
2210
A108Gr1211
