REPEATABILITY
0.1% of span
CALIBRATION CHECK
Built in Electronic Calibration (EC) Mid scale 2500/2.50.
RECORDER OUTPUT
0-10 VDC @ 5 mA max. (linear); standard on all models
OUTPUT IMPEDANCE
100Ω ±5%
SENSOR INPUT
1 (sensor included)
CONTROL FUNCTION
ALL Models:
Single set point alarm/control continuously adjustable
0-100% of span
Hysteresis
Adjustable from 0.3-6% of full scale
Indicators
“HIGH” (red) and “LOW” (green) set point LED.
Relay Contact Rating X 2
SPDT 10 amp @ 115 VAC, 30 VDC. Relay operates on
increasing reading.
Fused Outputs (2)
5 amp @ 115/230 VAC.
INPUT POWER SPECIFICATIONS
115/230 VAC ±15%, 50/60 Hz (User selectable) overvoltage
category II
100 mA Maximum Current
Double Insulated
Fuse - 100mA Slow Blow (T.10A) for both 115 & 230 VAC
(V~) User replaceable
Humidity - 20-90% non-condensing
Max. Altitude -
40,000 ft/12,000 meters non-operating
10,000 ft/3000 meters operating
Pollution degree 2
24 VAC Option available on Special Order
Overvoltage category II
250 mA Maximum Current
Double Insulated
Fuse - 250mA Slow Blow (T.25A) User replaceable
24 VDC Option available on Special Order
250 mA Maximum Current
Double Insulated
Fuse - 250mA Slow Blow (T.25A) User replaceable
AMBIENT TEMPERATURE RANGE
32°F ( 0°C) to 140°F (60°C)
DIMENSIONS
4.7” (120mm) H x 6.3” (160mm) W x 3.6” (92mm) D
HOUSING CONSTRUCTION
Fully gasketed heavy-duty ABS waterproof and corrosion
proof.
Rated IP65/NEMA 4X
Double Insulated
WEIGHT
CTCII: average 2 Ibs. (0.9 kg)
C. OPTIONAL FEATURES
-45 4 1/2 digit backlit liquid crystal display (LCD)
-35BL 3 1/2 digit backlit LCD
-24V 24 VAC isolated power supply (special order)
-24VD 24 VDC isolated power supply (special order)
-C4A 4-20 mA Output Module
-CS51R More Rugged Sensor (replaces the CSAR)
D. OPTIONS & ACCESSORIES
(ordered separately)
45O 4 1/2 digit backlit liquid crystal display (LCD)
35BLO 3 1/2 digit backlit LCD
C4AO 4-20 mA Output Module
LTMO Limit Timer Module Kit
442-3000 Calibration Solution (3000 ppm / 3900 µM/µS)
DOUBLE INSULATED
