Disassembling the hard disk drive module – Acer 505 User Manual
Page 61
Chapter 3
55
Disassembling the Hard Disk Drive Module
1.
To disassemble the hard disk drive module, first remove the six screws as shown here.
2.
Detach the left and right brackets from the hard disk drive.
3.
Remove the hard disk drive connection board from the hard disk drive.
505-1.book Page 55 Thursday, November 4, 1999 4:36 PM
