Panels
Ports allow you to connect peripheral devices to your computer as you would with a desktop PC.
NOTE: See chapter 3 on how to connect external devices to the computer.
Front Panel
The front panel contains ports for external audio connections.
#
Icon
Port
Connects to...
1
Speaker-out jack
Speakers or headphones
2
Audio line-in jack
Audio line-in device with a 3.5mm minijack (e.g.,
audio CD player, stereo walkman)
3
Microphone-in jack
3.5mm minijack condenser microphone
