95 Drawings
65K-2GJR Right Control HandleAssembly
ITEM QTY. PART NO./DESCRIPTION DESTINATION COMMENTS
1 1 30077R Right Control Handle Assembly
2 1 30079A Right Control Panel Assembly
3 2 A20 Button Air Valve Assembly
4 1 A80 'E' Stop Button Assy
5 1 20117A Rubber Shock Mount
6 4 806041_3.8-16 x 2.00 lg. Hex Bolt Grd. 5
7 6 805987-750 3.8-16 Flex Nut (21FKF616)
8 2 20247 Guard, Air Connector
9 12 810645_3.8 Lock Washer
10 12 806004_3.8-16 x .75 Lg. Hex Bolt
11 1 A51R-A Right Control Handle Coupler Assy See Explosion
12 2 806051_3.8-16 x 3.50lg. Hex Bolt
13 2 810648_3.8 Flat Washer
14 1 30081-1 Cover, Control Handle
15 4 810616-1 Lock Washer, 5.16 Hi Collar
16 4 805916_5.16-18 x .50 LG. HEX BOLT
17 1 30081-2 Cover, Right Control Handle
18 1 2081-4-2S 1.4 x 1.8 H.P. Hex Bushing
19 1 A46 5.32 x 1.8 PTC Elbow
20 1 A15 Air Manifold
21 1 65K-2JGR Torque Control Block Assembly See Explosion
22 1 HOS-18_1.8MNPTx1.8MNPTx54lg_1.8 Hose Gage Man. See Explosion
23 1 JHOS-14-30 10FJICx-10FJICx73.00lg. Hose Port P17, Main Man. See Explosion
24 1 JHOS-29-32 10FJICx-10FJICx55.00Lg. Hose Trq. Cyl, Piston See Explosion
25 1 HOS-30 1.8MNPTx1.8MNPTx73lg_1.8 Hose Port P11, Main Man. See Explosion
26 1 A53 5.32 Str Union Fitting
