65k-2gjr top-bottom wrench assembly, 73 drawings – Hawk Industries Hawkjaw Jr. Manual 65K-2GJR Serial Numbers 21 to 32 User Manual
Page 73
65K-2GJR Top-Bottom Wrench Assembly
73
Drawings
ITEM
QTY.
PART NO./DESCRIPTION
COMMENTS
1
1
30019 Base Plate Assy
2
1
30004A-3A Jaw Plate Assy
3
4
30029 Pivot Sleeve
4
4
30030 Pivot Pin
5
25
91074A036 Lock W asher Assembly, 3.4
6
4
806544_3.4-16 x 5.50 lg. Hex Bolt Grd. 9
7
4
806523_3.4-16 Flex Nut (31FK1216)
8
8
91074A038 Lock W asher Assembly, 1.0
9
2
806630_1.00-12 x 6.00lg. Hex Bolt
10
4
806594-500_1-14 Lock Nut
11
2
30056A Shoulder Bolt
12
1
65K-2GJR Top Heel Die Holder Assembly
See Explosion
13
2
92384A092 Push Button Pin
14
4
1103K2 Grease Fitting, 45 Degree
15
4
1103K3 Grease Fitting, 90 Degree
16
2
808413_1.2-13 x .75 lg. Soc. Hd. Cap Screw
17
2
30002 Hook Assembly
18
10
1103K1 Grease Fitting, Straight
19
8
806538-2 3.4-16 X 2.50 Lg Hex Bolt
20
2
30014-1 Clevis Plate, Hook Pin Assy
21
2
30014-2 Clevis Plate, Top-Bottom Hook
22
6
806453 5.8 X 4.0 Lg Hex Bolt
23
6
806414-500_5.8-11 Flex Nut (31FA1011)
24
2
30280 Adjust Nut Locking Assembly, JR
See Explosion
25
1
30005A-1 Die Pivot Block Assy
26
2
30035 Adjust Nut Assy
27
2
30034 Index, Nut
28
6
807801_ Pop Rivet
29
4
30115 Bolt, W rench
30
4
806646_1.1.4-12 Flex Lock Nut (31FK-2012)
31
1
30005A-3 Die Pivot Block Assy
32
1
30027-2 Lower Mount Angle Assembly
33
1
30017 Bottom Mount, Torque Cyl. Assembly
34
1
J20 Torque Cylinder Assembly
See Explosion
35
1
30111 Bumper, Torque Cyl.
36
2
J26 Grip Cylinder
See Explosion
37
1
30016 Top Mount, Torque Cyl. Assembly
38
4
30118 Angle Bracket Bolt, Large
39
2
30117 Angle Braket Bolt, Small
40
8
806529_3.4-16 x 1.75 lg. Hex Bolt Grd. 9
41
1
30110-1A Filter Bracket Exploded Sub-Assy
42
1
H25 Hydraulic Filter Assembly
See Explosion
43
1
65K-2GJR A22 On Board Air Filter Assembly
See Explosion
44
3
806025_3.8-16 x 1.50 lg. Hex Bolt
45
4
805847_1.4-20 x 1.00 lg. Hex Bolt
46
2
30055 Nut Retainer
47
2
30061 Clip, Nut Retainer
48
4
806004_3.8-16 x .75 Lg. Hex Bolt
49
2
98404A874_5.00lg.Quick Release Pin Assembly
50
4
2062-6-6S_6MORB x 6MJIC Fitting 90
51
3
806540_3.4-16 x 3.50 Hex Bolt
52
2
5682 (Spring 5.36 Lg)
53
2
2045-2-2S_2MNPT x 2FNPT Fitting Str. Swivel
54
1
2062-10-10S_10MORB x 10MJIC Fitting 90
55
1
2216-8-10S 1.2 FNPT X 7.8-14 Adapter
56
2
808401_3.8-24 X 1 1.2 Soc Set SS Cone Pt
57
2
808399_3.8-24 X 3.8 Soc Set SS Cone Pt
58
2
65K-2GJR Top-Bottom Hook Die Holder Assembly
See Explosion
59
2
810703_1.2 Lock W asher
60
7
810645_3.8 Lock W asher
61
4
810587_1.4 Lock W asher
62
1
65K-2GJR Bottom Heel Die Holder Assembly
See Explosion
63
1
30027-1 Upper Mount Angle
64
1
30004A-3B Jaw Plate Assy
65
1
30004A-1A Jaw Plate Assy
66
1
30004A-1B Jaw Plate Assy
67
4
30029-1 Pivot Sleeve Keeper
68
2
SL5 Danger Label
69
8
807800_ Pop Rivet
