65K-2GJR Spinner Assembly
75
Drawings
ITEM
Q TY.
P ART NO ./DES CRIP TIO N
CO M M ENTS
1
1
24703-JR Cas e, M oving A rm A s s em bly
2
4
95601A 435 Fiber W as her
3
1
24710-JR Cas e, S tationary A rm A s s em bly
4
3
24722 S pac er, G ear B ox
5
1
24CY L25-A S Grip Cy linder, Top
S ee E x plos ion
6
4
98404A 999_1x 5 11.16 QK P in
7
2
24637 B us hing
8
2
24729 F langed B earing
9
4
24646 W ear B loc k
10
1
24701 M ounting P late, G ear B ox
11
1
24625 Reduc er A s s em bly
S ee E x plos ion
12
3
807603 1.4 NP T P lug Hp
13
1
24642 K ey , Drive S proc k et
14
1
24641 Drive S proc k et
15
1
24635 S pac er, Drive S proc k et
16
1
24702 M ounting P late, B earing
17
1
24656 F lange B earing, M odified
18
1
24658 Chain G uard
19
2
806452_5.8-11 x 9.00 lg. Hex B olt
20
1
806450-1_5.8-11 x 7.00 lg. Hex B olt G rd. 9
21
5
810732_5.8 Loc k W as her
22
2
806416_5.8-11 Hex Nut
23
2
806435_5.8-11 x 1.50 lg. Hex B olt
24
4
810645_3.8 Loc k W as her
25
4
806025_3.8-16 x 1.50 lg. Hex B olt
26
1
M E 09 Hy draulic M otor A s s em bly , M anual
27
1
M 21 K ey
28
1
M 22 M otor M ount G as k et
29
1
R25 S un Gear K it
30
8
810703_1.2 Loc k W as her
31
4
806267_1.2-13 x 1.50lg. Hex B olt
32
2
24623 Roller S proc k et
33
4
24643 K ey , Roller
34
4
24649 Roller
35
4
RS T-275-S Retainer Ring
36
2
24CHA IN Chain
37
4
24654 B earing S eal A s s em bly
38
4
24731 S phere-Rol B earing
39
4
24622 B earing Cap
40
20
91074A 033 Loc k W as her A s s em bly , 1.2
41
20
806373_1.2-20 x 2.00 lg.Hex B olt G rd. 9
42
8
811150_#14 B ras s W as her
43
8
805834_1.4-20 x .50 lg. Hex B olt
44
2
98404A 878 Q uic k Releas e P in
45
1
91268A 935_1.0-8 x 9.50 lg. Hex B olt
46
2
91074A 038 Loc k W as her A s s em bly , 1.0
47
1
806580_1.0-8 Loc k Nut
48
1
DV S pinner M otor V alve A s s em bly , JR
S ee E x plos ion
49
3
805920 5.16-18 x 1.5 B olt
50
3
810616_5.16 Loc k W as her
51
9
1103K 1 G reas e Fitting, S traight
52
1
25726 Chain O iler A s s y
S ee E x plos ion
53
4
806251_1.2-13 x 1.25 Hex B olt
54
4
2081-8-6S 1.2 X 3.8 HP Hex B us hing
55
5
2089-6-6S _6M NP T x 6FNP T Fitting 90 E lbow
56
2
2090-6-6S NP T 3.8 Tee E lbow
57
4
810589_1.4 F lat W as her
58
5
810587_1.4 Loc k W as her
59
4
805842_1.4-20 x .75 lg. Hex B olt
60
2
2024-12-8S 12 M NP T X 8M JIC 90 Drg
61
2
2046-8-8S 1.2 HS S wivel Coupling F XF
62
1
805867 1.4-20 X 1 1.2 Hex Tap S S
63
1
805780 1.4-20 Hex Nut S S
64
2
2083-6-6S 3.8 Hex Nipple
65
2
2021-6-6S 6M NP TX6M JIC Fitting S tr
66
2
2047-6-6S 3.8 HP 90 Drg S T E L HS S W IL FXM
67
1
24723 Rubber Cover
68
2
2061-10-8S _10M O RB x 8M JIC Fitting 45
69
1
24CY L25-B S Grip Cy linder, B ottom
S ee E x plos ion
70
1
JHO S -2-54_-8FJICx 1.2M NP T Hos e33.00 Lg. Hos e
71
1
JHO S -1-53_-8FJICx 1.2M NP T Hos e33.00 Lg. Hos e
72
1
30142 P ipe A djus t P os ition Label
73
4
807801_ P op Rivet
