Spinner Drive Motor Assembly
Drawings
143
Drawings
ITEM NO. QTY./ASSY.
PART NO./DESCRIPTION
COMMENTS
1
7
031-M01 Special Bolts
2
1
031-M02 End Cover
3
1
031-M03 Seal Ring-Commutator
Only in kit #031-ME09-RK
4
5
031-M04 Seal Ring
Only in kit #031-ME09-RK
5
1
031-M05 Commutator Assembly
6
1
031-M06 Commutator Assembly
7
1
031-M07 Manifold
8
1
031-M08 Rotor Set
9
1
031-M09 Wear Plate
10
1
031-M10 Drive Link
11
1
031-M11 Thrust Bearing
12
1
031-M12 Coupling Shaft
13
1
031-M13 Inner Bearing
14
1
031-M14 Thrust Washer
15
2
031-M15 Thrust Bearing
16
1
031-M16 Inner Seal
Only in kit #031-ME09-RK
17
1
031-M17 Backup Washer
Only in kit #031-ME09-RK
18
1
031-M18 Service Housing Assembly
19
1
031-M19 Outer Bearing
20
1
031-M20 Dirt & Water Seal
Only in kit #031-ME09-RK
21
1
031-M21 Key
