Hanging cable requirements – Hawk Industries Hawkjaw Jr. Manual 65K-2GJR Serial Numbers 21 to 32 User Manual
Page 10
1. 5/8" diameter steel cable.
2. Appropriate hanging cable hardware for 5/8" diameter steel cable.
3. Enough cable length to suspend the Hanger Eye (HE) 20' ft. above the rig floor.
4. Enough cable length to allow the HawkJaw to rest on the rig floor 3'- 5' ft. away from the
rotary table with the lift cylinder completely stroked out. The lift cylinder is 13' ft. long
when completely stroked out.
Hanging Cable Requirements
10
Installation
HE
