65K-2GJR Main Manifold Air Connections
83
Drawings
ITEM
Q TY.
PAR T N O ./D ESC R IPTIO N
C O MMEN TS
1
1
J 1 Main Manifold, J R
2
3
2062-6-6S _6MORB x 6MJ IC Fitting 90
3
3
206209-6-6S_6MORB x 6MJ IC Fitting 90 Ext.
4
1
206209-10-10S _10MORB x 10MJ IC Fitting 90 Ext.
5
1
2062-12-8S_12MORB x 8MJ IC Fitting 90
6
2
2216-2-4S _-4MORB x-4FNPT Str. Adaptor
7
2
2047-2-2S 2MNPTX 2FNP T Fitting 90 D rg Swivel
8
2
900598-6S_MORB Plug
9
2
206209-8-8S_8MORB x 8MJ IC Fitting 90 Ext.
10
3
20202702-6-4S _-6MORB x -4MJ IC Str. Adaptor
12
2
2216-12-12S 3.4 MORBX 3.4 FJ IC
13
1
2089-4-4S 1.4 St E lbow
14
1
2244-8-10S 1.2 FNP T X 10FJ IC A dapt 90 D rg
15
10
A25 5.32 x 1.4 PTC Elbow
16
1
V6-1 Manifold Relief Valve Bloc k A ssy
17
1
V6B Relive Valve
18
1
H14_Torque V alve A ssembly
19
1
V5C Manifold Relief Valve Bloc k
20
1
H4D Port Plug
21
5
H6 Flow C ontrol Sandwic h Assembly
22
1
H9J R 3Grip Valve
23
2
H9J R 1&2 Grip Valve
24
1
H5 D irec tional Valve Assembly
25
2
H6PRM2_Pressure C ontrol Sandwic h
26
1
2089-2-2S 1.8 Straight 90 D rg Elbow
27
1
2045-2-2S _2MNPT x 2FNPT Fitting Str. Swivel
28
2
H71 1.4 QK D isc onnec t Male
29
1
H15_Spin Valve Assembly
30
2
2252-12-12S 3.4 HP Swivel 90 D rg
31
1
2062-12-12S_12MORB x 12MJ IC Fitting 90
32
1
FS55021 Swivel Fitting
33
1
30096 C onnec tor Brac ket
34
2
A10A L & R C oupler Assy
35
2
A40-5 Red Air Hose
36
2
A40-4 C lear Air Hose
37
2
A40-2 Orange Air Hose
38
2
A40-7 Green Air Hose
39
2
A40L-4_3.16 Blac k Air Hose
40
3
A40-1 Yellow Air Hose
41
2
A40-3 Blue Air Hose
42
1
A40-8 Gray Air Hose
