65k-2gjr top heel die holder assembly – Hawk Industries Hawkjaw Jr. Manual 65K-2GJR Serial Numbers 21 to 32 User Manual
Page 137
65K-2GJR Top Heel Die Holder Assembly
137
Drawings
ITEM Q TY. PART NO./DESCRIPTIO N
CO MMENTS
1
1
30031 Die Holder, Heel
2
1
20194 Die
3
2
20210 Roller Assembly
4
2
98381A622_3.8 Dia. x .75 lg. SS Dowel Pin
5
2
20208A Spac er Bushing, Roller
6
2
806303_1.2-13 x 3.50 Hex Bolt, Grade 8SLDPRT
7
2
810703_1.5 Loc k W asher
8
1
30012A-2A Top & Btm Die Retainer W elded Assy
