65K-2GJR Pipe Stop Assembly

103

Drawings

ITEM NO. QTY./ASSY.

PART NO./DESCRIPTION

COMMENTS

1

1

30049A Adjust Base

2

2

106 Ball Thrust Bearing Aseembly

3

1

30050 Adjust Screw

4

1

20061A Shock Sleeve

5

1

20070 Adjust Nut

6

1

807507-1 5.16 X 1 1.2 Dowel Pin

7

1

30051 Adjust Clevis

8

2

30023 Adjust Clevis Plate

9

1

30054 Pointer

10

1

30033 Index, Pipe Stop

11

2

809403-1_10-32 x .625lg. Phils. Hd Screw SS

12

4

807801_ Pop Rivet

13

1

30008 Pipe Stop Assembly

14

1

30058 Pipe Stop Rubber Mount

15

1

20029-1 W asher

16

1

30060 Pivot Bolt, Pipe Stop Modified

17

2

806313-2 1.2 -13 X 5.50 Lg Hex Bolt

18

1

806289_1.2-13 x 2.25lg. Hex Bolt

19

1

806221_1.2-13 Flex Nut

20

1

1103K1 Grease Fitting, Straight

21

2

809476_10 Lock W asher, High Collar

22

2

810703_1.2 Lock W asher
