5.3. Keypad Control
To allow the drive to be controlled from the keypad in a forward direction only, set P-12 =1:
1. Connect Motor as for terminal control above.
2. Enable the drive by closing the switch between control terminals 1 & 2. The display will show

.
3. Press the key. The display shows

.

.
4. Press to increase speed.
5. The drive will run forward, increasing speed until is released.
The rate of acceleration is controlled by the setting of P-03, check this before starting.
6. Press to decrease speed. The drive will decrease speed until is released. The rate of deceleration is limited by the setting in P-
04
7. Press the key. The drive will decelerate to rest at the rate set in P-04.
8. The display will finally show

at which point the drive is disabled
9. To preset a target speed prior to enable, press the key whilst the drive is stopped. The display will show the target speed, use the
& keys to adjust as required then press the key to return the display to

.
10. Pressing the key will start the drive accelerating to the target speed.
To allow the drive to be controlled from the keypad in a forward and reverse direction, set P-12 =2:
11. Operation is the same as when P-12=1 for start, stop and changing speed.
12. Press the key. The display changes to

.

.
13. Press to increase speed
14. The drive will run forward, increasing speed until is released. Acceleration is limited by the setting in P-03. The maximum speed is
the speed set in P-01.
15. To reverse the direction of rotation of the motor, press the key again.
