14.2 Connecting M70 to Connection Box
Connection between the M70 and the connection box is made according to the
illustration below.
Minimum Bending Radius of Cable
The drawing below shows the minimum distance required outside and inside
the control cabinet.
Connection box CB211
Power supply,
enabling switch
emergency switch,
CABTTxxx
RS232C/
Ethernet
