Technical Data
Beijer Electronics, MAEN843A 25
12 Technical Data
M70 specifications
Parameter M70
Size, diameter
height (incl. handle) 250 mm
114 mm
Seal IP65 (when USB host cover is closed).
Keyboard material Membrane keypad with tactile feedback.
Front panel Touch screen: Polyester on glass, 1 million finger touch
operations.
Housing Double-walled ABS housing. Withstands grease, oil,
lubricants, alcohol, etc.
Flammability class UL 94-V0
Weight 1.25 kg (incl. emergency stop and key switch, excl.
cable)
Serial port RS232C 9-pin D-sub contact, male with standard locking screws
4-40 UNC.
Ethernet 10 Mbit/s
USB USB 1.1 host interface
USB 1.1 client interface
Flash memory for
application 64 MB
Real time clock Without battery backup
Power consumption at
rated voltage 9.6 W (400 mA at 24 V DC)
Normal: 0.4 A
Maximum: 0.9 A
Display TFT-LCD. 640 x 480 pixels, 64K color.
Analog-resistive touch screen.
Background lightning: 2 CCFT cold cathode tubes with
50,000 h lifetime at 25
°C in continuous operation.
Active area of display,
W x H 6,5" (132x 98 mm)
